Toy Horizontal Thrust Tester TW-404
Toy Horizontal Thrust Tester TW-404-Manufactuer
This instrument is used to test the stability performance for activity toys and swings
Technical Specifications
Model | TW-404 |
Force Capacity | 3kN |
Force Loading Direction | horizontal |
Force Loading Actuator | four stations |
Force Accuracy | dynamic ±5% |
Force Resolution | 1/1000 |
Loading Stokes | 28cm |
Force loading point Height | 30~180cm |
Test Speed | 0~500mm/min adjustable |
Rise and up Speed | 800mm/min |
Time | 0~9999 adjustable |
Force Control | closed-loop control |
Motion | Servomotor |
Control | PC+ professional test software |
Machine Dimension(WxDxH) | 280x120x240cm |
Net Weight | ≈650Kg |
Power Supplier | 1∮ AC 220V 50Hz 3A |
Standards
IS9873-4,
ISO 8124-4 6.1.2 Stability of activity toys with a free height of fall of more than 600 mm (see 4.5.3);
ISO 8124-4 6.1.2 6.1.4 Stability of swings and other activity toys with crossbeams (see 4.7.1)
EN71-8 6.2.4 Stability of swings and other activity toys with crossbeams
