ASTM F963 Standard Pressure Head TW-246A-Manufacturer-HUST TONY
ASTM F963 Standard Pressure Head TW-246A
ASTM F963 Standard Pressure Head TW-246A .Suitable for any toy surface, during throwing, accessible to children and possibly in contact with flat surfaces, to assess whether the product meets the sharp point requirements.
It meets standard:
ASTM F963 2011.8.10.1
Technical Specifications
Model | TW-246A |
Product Size | 28mmx28mmx19 mm Diameter :28士0.38mm round handle Thickness: 9.52mm Edge chamfer radius: 0.8mm |
Package Size | 230 * 130 * 85mm (L * W * H) |
Material | Stainless steel |
Test Method
1.The sample must be placed for 4 hours at room temperature of 23±2 °C and humidity of 20%~70% before the pressure test;
2.Place the pressure head parallel to the test surface and press up to the desired number of pounds(110N+5N pressure) for 10 seconds within 5 seconds. (The toy should be placed in any suitable position on a flat, hard surface during testing)
Requirements and Judgments
1.Requirements:
American Standard (ASTM/CPSC):
0 ~ 18 months 20±0.5LBS
18～36 months 25±0.5LBS
36~96 months 30±0.5LBS
European Standard: 110N±5 N
Chinese Standard:
114N±2.0 N under 36 months
136±2.0 N between 37 months and 96 months
2.If sharp edges, sharp points, and small objects appear after the test, it is considered unqualified.
Standards
ASTM F963 2011.8.10.1
